Clamp Assembly Heavy Series Size 8S Ø102mm Aluminium W1 Weld Plate Cover Plate, Hex Head Bolt Profiled, with Initial Tension

SPAL-8102-AL-DPAL-AS-M-W1

Name: SPAL-8102-AL-DPAL-AS-M-W1
Brand: STAUFF
SKU: SPAL-8102-AL-DPAL-AS-M-W1
Price: 419.38 GBP

STAUFF Material No. 1110002959

View Technical details

Quantity in pieces

Check pricing and stock availability

List price

This material is only available on request.

Add to Enquiry List

If you have a regular demand for pipework equipment and hydraulic components and you are looking for individual pricing for our product range, please contact STAUFF.

Purchases can be made using credit/debit cards. However, if you would like to register, please contact STAUFF before filling the shopping cart. Your registration request will then be reviewed within a very short time.

Technical details
Bill of materials

STAUFF Online Page-Flip Catalogue

Navigate and search content, forward via email, print, and download in PDF format

Open STAUFF Online Page-Flip Catalogue in New Tab

STAUFF product catalogue

Download catalog

Standard

DIN 3015-2

STAUFF Series

Heavy Series

STAUFF Size

Group 8S (DIN 3015 Size 6)

Type of Installation

Single Weld Plate

Mounting & Fitting Combination

Cover plate / Hex. Head Bolt

Installation of Pipes

yes

Installation of Hoses

Installation of Cables

fixed installation of line

yes

sliding installation of line

Vibration Reducing

Tension Clearance

yes

Inside Surface

Profiled

for Diameter (mm)

102

Material (Clamp Body)

AL Aluminium

Material (Weld Plate)

Steel, Uncoated

Material (Cover Plate)

Steel, Uncoated

Material (Bolt)

Steel, Uncoated

Thread Type (Screws)

M20x190

Gross Weight

8.797 kg

Country of origin

Germany

Customs tariff number

7616991099

Packaging unit

1 piece

The product shown above is a kit consisting of several individual components. It is not always possible to order all individual components of a kit separately in the STAUFF online shop. Below you will find an overview of all purchasable individual components of the kit. Please note: If you order these components individually, please make sure to check that the kit is complete to ensure that it functions properly.
